Film Grain

An animated film grain overlay for any section, drawn on the GPU and blended with what sits beneath it.

Installation

pnpm dlx shadcn@latest add @uigrove/film-grain

Dependencies: none. Installs @uigrove/dot-canvas alongside.

First time? Add the registry to components.json

{
  "registries": {
    "@uigrove": "https://uigrove.me/r/{name}.json"
  }
}

Usage

import { FilmGrain } from '@/components/uigrove/film-grain'

<FilmGrain className="absolute inset-0" />

Props

Name	Type	Default	Description
intensity	number	0.5	Contrast of the grain against the surface
size	number	1	Grain cell size in CSS pixels
speed	number	1	How fast cells re-roll, 0 freezes the grain
blend	'overlay' \| 'soft-light' \| 'screen' \| 'normal'	'overlay'	CSS mix-blend-mode applied to the grain layer
monochrome	boolean	true	Monochrome
fps	number	24	Maximum redraws per second
className	string	—	Classes for the root element. Use it for sizing and position.

Code

'use client'

import { useEffect, useRef, type CSSProperties } from 'react'
import { useDotCanvas } from '@/hooks/use-dot-canvas'
import { FilmGrainEngine, type FilmGrainOptions } from './film-grain.engine'

export interface FilmGrainProps extends Partial<FilmGrainOptions> {
  className?: string
  style?: CSSProperties
}

export const filmGrainDefaults: FilmGrainOptions = {
  intensity: 0.5,
  size: 1,
  speed: 1,
  blend: 'overlay',
  monochrome: true,
  fps: 24,
}

export function FilmGrain({
  intensity = filmGrainDefaults.intensity,
  size = filmGrainDefaults.size,
  speed = filmGrainDefaults.speed,
  blend = filmGrainDefaults.blend,
  monochrome = filmGrainDefaults.monochrome,
  fps = filmGrainDefaults.fps,
  className,
  style,
}: FilmGrainProps) {
  const engineRef = useRef<FilmGrainEngine | null>(null)
  if (!engineRef.current) engineRef.current = new FilmGrainEngine(filmGrainDefaults)
  const engine = engineRef.current
  const { containerRef, canvasRef, wake } = useDotCanvas(engine, { pointer: false, kind: 'webgl' })

  useEffect(() => {
    engine.setOptions({ intensity, size, speed, blend, monochrome, fps })
    wake()
  }, [engine, wake, intensity, size, speed, blend, monochrome, fps])

  return (
    <div
      ref={containerRef}
      className={['uig-film-grain', 'pointer-events-none overflow-hidden', className]
        .filter(Boolean)
        .join(' ')}
      style={style}
      aria-hidden="true"
    >
      <canvas
        ref={canvasRef}
        className="uig-film-grain__canvas block h-full w-full"
        style={{ mixBlendMode: blend }}
      />
    </div>
  )
}
